| Honda Dio 125 X-Edition General Features | |
|---|---|
| Engine Type |
4 Stroke, SI Engine
|
| Brakes |
Disc
|
| Gear Box |
-
|
| Fuel Tank Capacity |
5.3 L
|
| Tyre Type |
Tubeless
|
| Honda Dio 125 X-Edition Standard Features | |
|---|---|
| Brakes | Disc |
| Pass Switch | |
| ABS | |
| CBS | Combi Brake System |
| Ebs | |
| Body Graphics | |
| Shutter Lock | |
Pearl Igneous Black
Pearl Deep Ground Gray Emblem
Pearl Siren Blue And Pearl Deep Ground Gray X-Edition
Imperial Red
Pearl Sports Yellow
Mat Marvel Blue Metallic
Pearl Deep Ground Gray Stripe
| Honda Dio 125 X-Edition Engine & performance | |
|---|---|
| Engine Type |
4 Stroke, SI Engine
|
| Displacement |
123.92
|
| Mileage |
-
|
| Bore |
50 mm
|
| Stroke |
63.113 mm
|
| Compression Ratio |
10:0.1
|
| Maximum Power |
8.30 PS @ 6500 rpm
|
| Maximum Torque |
10.5 Nm @ 5000 rpm
|
| Starting |
Self Start Only,Remote Start
|
| Maximum Speed |
-
|
| Honda Dio 125 X-Edition Transmission | |
|---|---|
| Gear Box |
-
|
| Clutch |
Automatic Centrifugal Clutch Dry Type
|
| Transmission Type |
Automatic
|
| Honda Dio 125 X-Edition Fuel | |
|---|---|
| Fuel Capacity |
5.3 L
|
| Supply System |
-
|
| Fuel Reserve |
1.3 L
|
| Fuel Gauge |
Digital
|
| Digital Fuel Gauge |
-
|
| Honda Dio 125 X-Edition Brake | |
|---|---|
| Brakes |
Disc
|
| Front Brake |
Disc
|
| Rear Brake |
Drum
|
| Honda Dio 125 X-Edition Tyre Size | |
|---|---|
| Tyre Size |
Front :-90/90-12 Rear :- 90/100-10 |
| Radial Tyres |
-
|
| Honda Dio 125 X-Edition Wheel Size | |
|---|---|
| Wheel Size |
Front :-304.8 mm, Rear :-254 mm |
| Wheel Base |
1260 mm
|
| Honda Dio 125 X-Edition Chassis and Suspension | |
|---|---|
| Bike Suspension |
-
|
| Honda Dio 125 X-Edition Frame | |
|---|---|
| Chassis/Frame |
-
|
| Honda Dio 125 X-Edition Electrical | |
|---|---|
| Ignition |
-
|
| Battery Type |
-
|
| Head Lamp |
-
|
| Tail Lamp |
-
|
| Turn Signal Lamp |
LED
|
| Honda Dio 125 X-Edition Exterior Dimensions | |
|---|---|
| Length | 1830 mm |
| Height | 1172 mm |
| Width | 707 mm |
| Ground_Clearance | 171 mm |
| Saddle_Height | 708 mm |
| Kerb Weight | 105 kg |
| Total Weight | - |
| Weight_Carrying_Capacity | - |
| Chassis/Frame | - |
| Wheel Base | 1260 mm |
